Xdim G3 Docking Interface Module

Get a Price/Quote

MOQ : 1 Piece

Xdim G3 Docking Interface Module Specification

Dimension (L*W*H)
Approx. 220 x 110 x 35 mm

Mounting Type
Panel Mount/DIN Rail

Temperature
-10C to +60C

Standard
Complies with IEC and RoHS Guidelines

Weight
Approx. 410 g

Material
High-grade Industrial Plastic and Metal Alloys

Input Voltage
110-240V AC

Product Type
Docking Interface Module

Tolerance
0.05 mm

Surface Treatment
Anodized/Anti-corrosion Coating

Technique
Injection Molding & Metal Stamping

Usage
Multiple Device Docking and Data Communication

Process
CNC Fabricated

Design
Modular, User-friendly Docking Layout

Output Voltage
5V/12V DC Outputs supported

Color
Grey/Black

Equipment Type
Interface Module

Processing
Precision Machined

Installation Guideline
Panel Mount or DIN Rail Installation as per manufacturer manual

Finish
Matte/Anti-glare

Frequency
50/60 Hz compatible input

Application
Industrial Automation, Robotics, Test & Measurement, Control Systems

IP Rating
IP54

Supply Voltage
24V DC Nominal

Service Period
Up to 5 Years (depending on operating conditions)

Humidity
10% - 90% RH, Non-condensing

Size
Compact

Thickness
Enclosure: 2.5 mm

Number of Docking Ports
4 Independent High-Speed Ports

Enclosure Material
Flame Retardant ABS Body with Reinforced Steel Plates

Vibration Resistance
Up to 5 g (per IEC 60068-2-6)

Connector Type
Industrial-grade Locking Connectors

LED Indicators
Power, Data Activity, Docked Status

Communication Protocols Supported
RS232/RS485, USB 2.0, Ethernet (depending on module variant)

Power Consumption
Max 15W

Compatible Devices
PLC, Sensors, Actuators, Industrial PCs

Xdim G3 Docking Interface Module Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About Xdim G3 Docking Interface Module

Get ahead in industrial connectivity with the Xdim G3 Docking Interface Module-a popular, highly recommended choice for seamless equipment integration. This brilliant champion boasts four independent high-speed ports and supports an array of communication protocols such as RS232/RS485, USB 2.0, and Ethernet. Its gilt-edged, industrial-grade locking connectors ensure a secure fit. Designed for durability with a flame-retardant ABS body and reinforced steel plates, it withstands vibration up to 5g. LED indicators, modular layout, CNC precision, and IP54 rating make it a user-friendly, long-lasting, and reliable solution for industrial automation, robotics, and test systems across India.

Xdim G3 Docking Module: Special Features & Applications

The Xdim G3 Docking Interface Module stands out with its user-friendly modular design, robust flame-retardant enclosure, and precision-machined build. Four high-speed, independent ports enable flexible device docking, making it ideal for PLCs, sensors, actuators, and industrial PCs. Its anti-corrosion, matte-finished surface ensures longevity in demanding environments such as automation, robotics, test and measurement, and control systems. Industrial-grade locking connectors and comprehensive LED indicators simplify operation, making it a preferred choice for high-reliability applications.

Main Domestic Market & Shipping Highlights

Xdim G3 Docking Interface Module serves the highly dynamic industrial sectors across India. With sample availability, customers can evaluate quality before full-scale orders. Upon order completion, modules are promptly dispatched via secure shipping channels, ensuring swift and safe delivery. Typical delivery time is quick and efficient, aligned with industry demands. The service provider and supplier support ensures a hassle-free purchase process, confirming that your equipment arrives intact and ready for installation in any facility nationwide.

FAQ's of Xdim G3 Docking Interface Module:

Q: How easy is it to install the Xdim G3 Docking Interface Module?

A: Installation is straightforward, offering both panel mount and DIN rail options as per the manufacturer's instructions. The user-friendly modular layout and compact size facilitate quick integration into existing systems.

Q: What devices are compatible with this docking interface module?

A: The Xdim G3 Docking Interface Module is compatible with PLCs, sensors, actuators, and industrial PCs, making it versatile for a range of industrial automation and control applications.

Q: When can I expect the delivery after placing an order?

A: After order completion, the module is dispatched promptly through secure shipping, and typical delivery times are fast, depending on your location within India.

Q: Where can the Xdim G3 Module be used?

A: It is designed for industrial environments including automation units, robotics, test and measurement labs, and control systems requiring robust and reliable device communication.

Q: What are the benefits of the flame retardant and anti-corrosion enclosure?

A: The flame-retardant ABS body with reinforced steel plates and anti-corrosion surface provides superior protection, making the unit highly reliable in challenging industrial conditions.

Q: How does the LED indicator system assist users?

A: LED indicators display power, data activity, and docked status, offering immediate and clear feedback to users and simplifying monitoring and troubleshooting during operation.
